Why the Haas F1 car floor was ruled illegal in Italian Grand Prix

Despite the complexity of Formula 1's rulebook, and the intense battle between teams, it is quite rare for post-race protests to take place these days

Why the Haas F1 car floor was ruled illegal in Italian Grand Prix

That is why there was surprise after the Italian Grand Prix when Renault protested the Haas car for an illegal floor. It is believed to be the first protest since Lotus (the previous name of the Renault team) complained about the Mercedes double-DRS system in 2012.

An investigation by the Italian GP stewards concluded that the Haas floor did not comply with the regulations, which had been subject to a technical clarification sent to teams before the summer break.

In that Technical Directive, the FIA deemed that designs like Haas used were no longer allowed to race - but the American-owned outfit had asked for a stay of execution until the Singapore Grand Prix later this month while it worked on changes.

But at least one other team was able to make the necessary modifications, and the FIA warning Haas that if it did not alter the car it risked a protest from a rival team.

The debate over the legality of the Haas VF-18's floor is in regard to an area known as the T-Tray or splitter - the flat area that the plank is attached to and stretches out at the front underneath the raised nose area of the car.

F1 rules deem that the front area of this splitter needs to be shaped in a certain way.

Article 37.1 states the surface formed by all parts lying on the reference plane must "Have a 50mm radius (+/-2mm) on each front corner when viewed from directly beneath the car, this being applied after the surface has been defined."

The below image from the FIA rulebook makes clear where the 50mm radius needs to be.

It is this floor area of the car that was altered when Haas brought an update for the Canadian Grand Prix earlier this year.

While the floor maintained the previously legal 50mm radius, it was the way the team attached a new footplate design and connected it to this splitter which is at the centre of the argument.

By making these changes, it prompted some debate about what was a floor surface and what was not. That interpretation influenced whether the 50mm radius measurement could be taken or not.

By pulling the attachment right to the area where the 50mm radius is supposed to be, it put it in a grey area.

The rules are clear that the 50mm radius must be seen when viewed from below: but having the bargeboard attached further forward moved it into a location where it could be interpreted that the 50mm radius was no longer visible.

As can be seen in the below comparison photographs which have kindly been supplied to us by Albert Fabrega, the changes made to the Haas at the Canadian Grand Prix have made it much harder to define where that outer corner of the floor is.

This area of the car is extremely sensitive due to its proximity to the ground, making it rife for development. It is something that other teams cannot afford to turn a blind eye to, whether that be in terms of letting their adversaries make gains or stealing a charge themselves.

And with Haas locked in a tight fight with Renault for fourth place in the constructors' championship, its progress was always going to come under the spotlight of the French manufacturer.
