Analysis: Gary Anderson's stories to watch in Jerez 2014 F1 test

Ex-Formula 1 designer Gary Anderson will be providing technical insight for AUTOSPORT throughout the 2014 season

Analysis: Gary Anderson's stories to watch in Jerez 2014 F1 test

Ahead of the start of winter testing at Jerez on Tuesday morning, he picks out six key storylines to watch during the early running.

HOW MANY LAPS WILL CARS MANAGE?

Or to be precise, how many consecutive laps can they do? The main focus for the first day is going to be on getting the engine and the electrical power package functioning together and you can't take risks with that sort of thing.

You just have to put the mileage in on it so I am expecting lots of installation laps to start with and then people starting to put in proper runs later in the day.

FIRST VIEW OF THE RED BULL

Red Bull has dominated the last four years of F1 and Adrian Newey has traditionally thrived with new regulations. When the regulations changed in 2009 it was Red Bull's big chance because others lost momentum and the team had a clean sheet of paper.

This is the other side of that clean sheet of paper. Red Bull has set the standards, but has to do so again to stay at the front.

It will be fascinating to see the car concept, particularly the nose. There seem to be three different styles - the anteater, the platypus and the twin tusk, so which will Red Bull choose?

TURBOCHARGERS RETURN TO F1

Turbos are back, but these will be very different to the turbo packages last seen at the end of 1988.

The rules allow a single turbo, but it's a large one because there is an electrical motor used to spin it up to match the engine and avoid lag. The motor will also hold the turbo back to avoid having overboost, hence no wastegate.

Although the engine manufacturers have transcient dynos it's never quite the same as in the real world. So this is the first stage of a steep learning curve about how the turbo functions.

DRIVING STYLE CHANGES

There is a lot more torque with the new engine packages, so the aim for the drivers is to deliver the maximum usable amount. It's all about the driving style.

What we have seen recently is cars being driven very differently from corner to corner but the driver now needs to be very consistent. The fuel consumption must be consistent and the electrical torque must be consistent.

If the driver is not consistent, it will cause problems. So there's another big learning curve.

It will be easy to spin the wheels, to spin up the rear tyres and it will be very easy to use more fuel.

THE NEW SOUND OF F1

Engine noise is part of motor racing and it has always been about being able to feel the high rpm in your bones.

It wasn't long ago that the old V8s were putting out in excess of 20,000rpm prior to the 18,000rpm rev limit. The new engines have a limit of 15,000rpm. And because of the fuel flow limit, we might not hear that very often.

The days of shrill engines are gone as the turbocharger effectively acts as a silencer. And the tailpipes are bigger to avoid back pressure building up, so you will get a slower exhaust gas speed.

The need to wear ear plugs is probably a thing of the past.

BATTERY PACKAGE CONTROL

The battery package now has 10 times the capacity of the old battery pack, so keeping that under control temperature-wise while charging and discharging it is a challenge.

The problem with that is that to charge it you have to use the brakes hard, so you have to drive the car quickly.

That creates a chicken and egg situation where you have to lean on the car when you are trying to check the systems are functioning early on.

JEREZ TEST LINE-UP

Team Day 1 Day 2 Day 3 Day 4
Red Bull Sebastian Vettel Sebastian Vettel Daniel Ricciardo Daniel Ricciardo
Mercedes Lewis Hamilton Nico Rosberg Lewis Hamilton Nico Rosberg
Ferrari Kimi Raikkonen Kimi Raikkonen Fernando Alonso Fernando Alonso
McLaren Jenson Button Jenson Button Kevin Magnussen Kevin Magnussen
Force India Sergio Perez Nico Hulkenberg Daniel Juncadella TBC
Sauber Esteban Gutierrez Esteban Gutierrez Adrian Sutil Adrian Sutil
Toro Rosso Jean-Eric Vergne Daniil Kvyat Jean-Eric Vergne Daniil Kvyat
Williams Valtteri Bottas Valtteri Bottas Felipe Massa Felipe Massa
Marussia Max Chilton Jules Bianchi Max Chilton Jules Bianchi
Caterham Marcus Ericsson Marcus Ericsson Robin Frijns Kamui Kobayashi

Follow testing as it happens with AUTOSPORT Live - including Gary Anderson's technical insights - from Tuesday morning
