Lotus's 2014 Formula 1 car's twin tusk theory explained

AUTOSPORT technical expert CRAIG SCARBOROUGH explains the thinking behind Lotus's 'twin tusk' 2014 Formula 1 car and its distinctive front

Lotus's 2014 Formula 1 car's twin tusk theory explained

The look of the nose of 2014's Formula 1 cars has already been a major talking point, but Lotus caused a fresh stir by releasing a rendering of its new E22, which features a very different philosophy.

AUTOSPORT has learned that the aggressive 'twin tusk' arrangement caused problems for the team in completing crash testing.

But this hurdle has been overcome and Lotus will be ready to go in time for the second pre-season test in Bahrain.

The rules mandating a single nose tip, to be mounted far lower than previously and with a minimum cross section, were introduced for safety reasons.

The other cars that have so far been revealed have featured the 'anteater' nose, which forms the nose tip with a finger-like extension.

Gallery: 2014 F1 designs so far

Lotus's twin tusk arrangement eschews this philosophy and stretches the wording of the rules to the limit.

In order to meet the single lower nose tip regulation, the two tusks are of unequal length, so the longer one forms the mandatory nose tip, while the other is short enough to avoid being considered part of the nose tip by the regulations.

This leaves each tusk to act as a crash structure, the front wing mounting pylon and then, as they slim narrow the rear of the car, also become turning vanes.

This means the unavoidable obstruction of the mandatory nose tip is made into a multi-purpose device.

The design may present slightly more total cross sectional area to the airflow, but places the obstruction in the most beneficial location.
